Most standard wheel stud patterns are available on request. Coupled with a choice of brakes including electrical or hydraulic drum brakes or hydraulic disc brakes. Mechanical Drum brakes are also available on smaller capacity units.

Most larger capacity units come equipped as standard with all steel hubs and replaceable brake drums or rotors which in turn reduces unsprung weight whilst greatly increasing strength.

Tandem units are available in either straight, overlay or drop configurations offering a wide variation of vehicle ride heights.

Wheel centres on On-road units are available to suit 14", 15" or 16" Wheels. Agricultural units from 4000kg to 6000kg, can be supplied with various wheel centres to cater for large diameter, high floatation tyres for reduced soil compaction.

Single units 750kg to 1600kg are available in either straight or overlay whilst 2000kg - 2500kg single units are available as straight or drop units.






Sectional view of Simplicity Pivot Bush. Featuring Steel Outer Bush, Steel Inner Bush and a polyurethane membrane. Used in conjunction with polyethylene thrust washers. Creating a complete maintenance free bushing system.

These pivot bushes are used on all Simplicity Axles. ™
